Power Cord Reel, Model #: L4545 12 3 3
power cord reel
Blue Bullet 45 foot, 12 AWG, 3 conductor cord
Blue Bullet Spring retractable with latch
Blue Bullet Wall or ceiling mount
Blue Bullet Adjustable cord stop
Blue Bullet NEMA 5-20P-H pre-installed on end of cord to mate with 20 amp WP, or Super Auto Eject
gray border
gray border
gray border
gray border
  • Power Cord Reel
    Specifications
  • Related
    Products
Cord: 45 Feet, 12 AWG, 3 Conductor, Oil Resistant SJO
Mating Conector: NEMA 5-20P-H Pre-Installed On Cord
Mounting: Wall or Ceiling
Weight: 28 lbs








Super Auto Eject 120 Vac, 15 Amp - 091-55-15-120
Super Auto Eject 120 Vac, 15 Amp, Back Wire - 091-55-15-120-BW
Super Auto Eject 250 Vac, 12 Vdc, 15 Amp - 091-55-15-DC
Super Auto Eject 250 Vac, 12 Vdc, 15 Amp, Back Wire - 091-55-15-DC-BW
Super Auto Eject 120 Vac, 20 Amp - 091-55-20-120
Super Auto Eject 120 Vac, 20 Amp, Back Wire - 091-55-20-120-BW
WP Auto Eject 120 Vac, 15 Amp - 091-18WP-120
WP Auto Eject 250 Vac, 12 Vdc, 15 Amp - 091-18WP-012
WP Auto Eject 120 Vac, 20 Amp - 091-20WP-120



This reel, manufactured by REELCRAFT, is an ideal accessory for the Auto Eject. Providing a 45-foot length of 12AWG oil resistant SJO cord, conveniently coiled on a spring loaded reel, simplifies the installation for both the installer, and the subsequent user. The standard NEMA 5-20P-H connector is installed to mate with the 20 ampere WP, or Super Auto Eject. For other models of the Auto Eject, the installer must replace this connector with the one supplied with the Auto Eject. An adjustable cord stop is set at installation to limit the retraction of the cord to the desired length, and to ensure that the cord does not create tension or side loads on the Auto Eject.
